    Used Full Automatic Servo Pull Up Pants Baby Diapers Production Line Adult Diaper

    Ask Lasest Price
    Brand Name : hi-create
    Certification : ISO\CE
    Price : us200000-1300000
    Payment Terms : L/C, D/A, D/P, T/T
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    Used Full Automatic Servo Pull Up Pants Baby Diapers Production Line Adult Diaper

    Used Full Automatic Servo Pull Up Pants Baby Diapers Production Line Adult Diaper Manufacture Machine


    Products Description
    Design speed
    600pcs/min
    Production speed
    500pcs/min
    Efficiancy
    ≥ 88%
    Finished Product
    ≥ 98%
    Machine Weight
    About 60 tons
    Machine Size
    30*3*3 (L*W*H)
    Operating Size
    35*7*5 (L*W*H)
    Machine capacity
    about 280 KW
    Power source
    380V, 50HZ three phase five wire
    Air pressure
    0.6-0.8MPA (37KW pump, 5.8cube/h)
    Machine color
    customlized
    Machine direction
    customlized
    Finished products
    S, M, L, XL

    Main Function Features

    1. Servo motors driving with PLC control and touch screen;
    2. High-speed teeth-like crusher;
    3. SAP auto adding with amount crusher;
    4. Servo unwinding, auto-tension control and auto splicing for raw material;
    5. Auto rejusting during running without stop;
    7. Diaper auto counting & stacking;
    8. With the LED display screen, displaying urgent stop indication and current speed.
    Configuration
    1. Product structure:
    Leg cuff N.W,Top sheet N.W,Fluff core(with SAP) Side Tape,ELastic waistband,Frontal tape,Back sheet.
    2. Product size:
    M: 680*450 L: 800*650 XL: 950*760
    3. Control system:
    PLC control system,operating on the touch screen,man-machine interface
    4.Tension system:
    Leg cuff N.W,Top sheet N.W,elastic waistband,upper & down tissue,back sheet are A & B shaft active unwinding by Inverter motor.
    5.Drive system:
    Timing belt and flat belt are imported products,and all the key parts are imported bearings.
    6.Safety system:
    It has safety device on the operating side,matched with urgent stop switch,high audio fan uses sound insulation or silencer.
    7.Materials corrective system:
    Germany BST automatic web guide system(optional)
